SkyRC B6 NEX AC 50W / DC 200W 10A Balance Charger with Bluetooth

£73.90 Inc. VAT

The B6 Nex is small in size, but big on power. It also has Bluetooth for connectivity with smartphones.

In stock

0 People watching this product now!
Description

The SkyRC B6 Nex AC/DC Battery Charger builds on the success of the iconic iMax B6. The B6 Nex is a high-performance solution designed for hobbyists of all disciplines.

With the dual power AC/DC input, B6 Nex can charge the 1-6 cell Li-ion or LiPo batteries at a maximum charge current of 10A. The maximum power of B6 Nex can reach up to 200W (DC, 50W on AC). Menu navigation is made easy with the intuitive three-button control interface. With the stunning backlit 2.4-inch VA screen, large viewing angle, high WBC, rapid response, all information is clear at a glance.The built-in Bluetooth 5.0 enables B6 Nex’s connectivity with smartphones. The app can push notifications reminding users that charge or discharge is completed. A unique feature of the B6 Nex is SCAN TO GO (automatically charging system): with the SkyCharger app, a unique QR code sticker can be printed and pasted on the battery. Since all the essential information is stored in the QR code, all you need to do is to scan the QR code, and the charge or discharge process will start automatically.ย Through the smart app, the charger can be quickly upgraded wirelessly. There is no need to buy an expensive legacy data cable for firmware upgrade through a computer. The firmware upgrade is made easy with the smartphone. With B6 Nex, charging becomes a faster and more convenient experience!

Cutting Edge with GaN Power!ย

By replacing silicon with gallium nitride, SkyRC has been able to implement their proprietary charging algorithm and optimal thermal dissipation technique to minimize the temperature rise, deliver more power, and shrink its size. The primary benefit is power to footprint ratio. GaN systems offer higher power output in a smaller size than a traditional charger. The con is that GaNย requires synthetic materials, which are much more difficult to manufacture than traditional silicon.

What is GaN?

Gallium nitride (GaN) is a very hard, mechanically stable wide bandgap semiconductor. GaN is used in the production of semiconductor power devices as well as RF components and light-emitting diodes (LEDs). GaN has demonstrated potential to be the replacement technology for silicon semiconductors in power conversion, RF, and analog applications. GaNโ€™s ability to conduct electrons more than 1000 times more efficiently than silicon, while being able to be manufactured at a lower cost than silicon has been well established. When compared to silicon, GaN is a superior choice.

Features:

  • Smallย Size, Big Power:ย Thanks to the lightweight structure and optimized firmware, B6 Nex can fit into your pocket. The maximum power of B6 Nex can reach up to 200W.
  • Stunning VA Display:ย Everything at a glance. Menu navigation is made easy with the intuitive three-button control interface. With the bright backlit 2.4-inch VA screen, large viewing angle, high WBC, rapid response, all information is clear at a glance.
  • Cutting Edge GaN Power:ย By replacing silicon semiconductors with gallium nitride, SkyRC has been able to implement a proprietary charging algorithm and optimal thermal dissipation technique that creates a small, yet powerful AC/DC charger option.
  • AC/DC Dual Power Input:ย B6 Nex comes with both AC and DC power input, to meet your power supply needs.
  • Multi-Chemistry:ย Charging algorithm for the most common battery chemistries: LiPo, Li-Ion, LiHV, LiFe, NiMH, NiCD, and Pb (lead acid).
  • Adjustable Cut-off Voltage:ย You can set charging cut-off voltage according to your needs. Furthermore, B6 Nex can memorize the last setting parameters.
  • Smart & Efficient Cooling:ย Temperature-controlled 12000rpm high-speed sleeve bearing cooling fan effectively blows the air through the extruded aluminum heat sink, cooling the unit down.
  • Bluetooth 5.0:ย Next generation Bluetooth technology. Faster and more stable connection. B6 NEX has a built-in Bluetooth 5.0 chip which data transmission rate is 2 times higher than that of Bluetooth 4.0, and the connection is faster and more stable.
  • Prompt Push Notifications:ย When charging or discharging is completed, the app automatically pushes to remind the user that the process is completed. The user will get a push notification whenever there is a software upgrade.
  • Scan to Go:ย A unique feature of the B6 Nex is the SCAN TO GO automatic charging system. With the SkyCharger app, a unique QR code sticker can be printed and pasted on the battery. Since all the essential information is stored in the QR code, all you need to do is to scan the QR code, and the charge or discharge process will start automatically without needing to manually update charge parameters.
  • Intuitive Android & iOS application:ย SkyCharger app available on App Store and Google Play.
  • Wireless Firmware Upgrade:ย Through the smart app, the charger can be quickly upgraded wirelessly. There is no need to buy an expensive legacy data cable for firmware upgrade through a computer. The firmware upgrade is made easy with your smartphone.
Specification

Power

  • DC Input : 10-30V
  • Charge: 200W
  • Discharge: 10W
  • AC Input: 100-240V(50-60HZ)
  • Charge: 50W
  • Discharge: 10W

Battery

  • BatteryTypes/Cells: LiPo/LiIon/LiFe/LiHV: 1-6cells
  • NiMH/NiCd: 1-15cells
  • Pb: 1-10S(2-20V)
  • Battery Capacity Range:
  • NiMH/NiCd: 100-50000mAh
  • LiPo/LiIon/LiFe/LiHV: 100-50000mAh

Charge and Discharge

  • Charge Voltage
  • NiMH/NiCd: Delta peak detection
  • LiPo: 4.18-4.25V/cell
  • LiFe: 3.58-3.7V/cell
  • Pb: 2.4V/cell
  • LiIon: 4.08-4.2V/cell
  • LiHV: 4.25-4.35V/cell

Discharge Cut-off Voltage

  • NiMH/NiCd:0.1-1.1V/cell
  • LiPo: 3.0-3.3V/cell
  • LiFe: 2.6-2.9V/cell
  • Pb: 1.8V/cell
  • LiIon: 2.9-3.2V/cell
  • LiHV: 3.1-3.4V/cell
  • Charge Current: 0.1A-10.0A
  • Discharge Current: 0.1A-2.0A
  • Balance Cells: 1-6 cells
  • Balance Current: 1000mA/cell Max
  • Safety Timer: 1-720minutes off
  • Charge Method:CC/CV for lithium types and lead(Pb) batteries.ย  Delta-peak Sensitivity for NiMH/NiCd.
Q&A

Questions and answers of the customers

There are no questions yet. Be the first to ask a question about this product.

Advice

lipo fire risk

Lithium Polymer (LiPo) Battery Safety Guidelines

PLEASE READ AND KEEP FOR REFERENCE

Lithium Polymer (LiPo) batteries can be extremely dangerous if not handled correctly. A lithium fire can reach extremely high temperatures, is unpredictable and difficult to extinguish.

A standard four-cell 1500mAh LiPo battery at full charge stores a massive 25Wh (watt hours) of energy!

Please take these risks seriously. We advise following the guidelines below to safely use and maintain your LiPo batteries.

Disclaimer

This information sheet is provided to help our customers understand LiPo battery safety. However, you use this information at your own risk. Following good practices will also help to ensure the longevity of your battery packs.

By purchasing LiPo batteries or charging equipment from our store, you accept all risks related to their use. If you disagree, please contact us immediately to arrange a return before using the product.


1. Charging Safety

  • Use a proper charger: Always charge LiPo batteries with a LiPo-compatible charger.
  • Set the correct parameters: Charge at the recommended voltage and current settings specified by the manufacturer. Many fires occur due to incorrect charge settings. In most cases, the safest charge rate is 1C.
  • Double-check connections: Ensure that charging leads are connected correctly. Reverse charging can lead to cell damage or a fire.
  • Charge in a safe environment: Charge batteries on a non-flammable surface, in a fireproof container, and away from flammable materials.
  • Monitor while charging: Never leave charging batteries unattended. Stop charging immediately if the battery becomes hot or swollen.
  • Avoid overcharging: Never exceed 4.2V per cell (4.35V for LiHV Lithium-ion Polymer High-Voltage batteries).

2. Storage Safety

  • Storage voltage: For long-term storage, maintain a โ€˜storage chargeโ€™ voltage of 3.7V to 3.85V per cell.
  • Store in a cool, dry place: Always store your LiPo pack in a safe and non-flammable container away from flammable objects. A LiPo sack or metal/ceramic storage container is best. Avoid direct sunlight or high temperatures (above 60ยฐC/140ยฐF). The ideal storage temperature is 10ยฐC to 25ยฐC (50ยฐF to 77ยฐF).
  • Avoid full discharge: Never store batteries at full charge or with a low voltage (below 3.3V per cell).

3. Handling and Usage

  • Inspect regularly: Check batteries for any damage, swelling, or leaks before use.
  • Avoid physical damage: Protect batteries from impacts, punctures, and exposure to moisture or water.
  • Never short-circuit: Avoid contact between battery terminals. Do not store or transport batteries where they can come into contact with sharp or conductive materials (e.g., metal objects).
  • Use within limits: Stay within the manufacturerโ€™s recommended discharge rate and capacity ratings for safe operation.
  • Monitor during use: Use voltage alarms or onboard monitoring to prevent over-discharging (below 3.3V per cell).
  • Crashes: If a battery is damaged in a crash or shows changes in appearance (including swelling or gassing), move it to a safe place to observe, and discard it. Never attempt to charge a battery with physical damage, regardless of how minor the damage may seem.

4. Disposal

  • Lifespan: Rechargeable LiPo batteries do not last forever. Batteries that have lost 20% of their initial capacity should be removed from service and disposed of.
  • Dispose properly: Never throw LiPo batteries in the general waste. Dispose of them at certified recycling centres.
  • Prepare for disposal: Fully discharge batteries before disposal and tape the terminals to prevent short circuits.

5. In Case of Fire

  • Fire containment: If a LiPo battery catches fire, use a Class D fire extinguisher or sand to smother the fire. Avoid inhaling fumes and vacate the area immediately.
