Holybro Kakute F405-Wing Mini – Wing Flight Controller

£42.90 – £64.90 Inc. VAT

Perfect for your smaller fixed-wing projects or anything looking to save space and weight.

Version

Clear

Compare

0 People watching this product now!

SKU: N/A Categories: Fixed Wing Autopilots, Electronics, Flight Controllers / Autopilots, Plane Flight Controllers, Planes & Wings, Plane Electronics, Airplane Gyros & Stabilizers Tags: Ardupilot, FC, Flight Controller, iNav, Kakute, Wing Flight Controller

Description

The Holybro Kakute F405 Wing Mini is a compact flight controller designed for fixed-wing and small UAVs, featuring the STM32F405 processor and the low-noise ICM-42688-P IMU with independent LDO for enhanced stability. It includes two onboard BECs for regulated power, an integrated barometer, I2C support, and analog OSD. Tailored for small aircraft, this flight controller delivers powerful performance and precision in a compact form, making it ideal for space-constrained setups.

Features:

STM32F405 MCU running at 168 MHz
High-Precision / low-noise ICM-42688-P IMU
2 On-board BEC output 5V, 5V/7.2V
On-board voltage & current sensor
Integrated SPL06 barometer
I2C port Support
Small & low-profile design fits into compact frames
Supports INAV (7.1.2 & later), Ardupilot (4.5.6 & later), Betaflight (4.5.2 & later)

Firmware Support

ArduPilot: Kakute F405 Wing Mini (4.5.2 & later)
INAV: Kakute F405 Wing Mini (7.1.2 & later)
Betaflight: Kakute F405 Wing Mini (4.5.6 & later)

Reference Link

Specification

MCU: STM32F405RGT6, 168 MHz, 192KB RAM, 1MB Flash
IMU: ICM-42688P (SPI1)
Baro: SPL06 (I2C2)
OSD: AT7456E (SPI2)
Onboard Blackbox: 128Mbits (SPI3)
5x Uarts (1,2,3,5,6) and R3 is with built-in inversion
7x PWM output, PWM7 used for NeoPixel LED by default
2x ADC (Bat1/Curr1)
1x I2C (the I2C2 is for external devices, also for onboard sensors)
2x LEDs for FC STATUS (Blue) and 3.3V indicator (Green)
USB/DFU Key Extender with USB Type-C
High-precision Current Sense (110A continuous, 132A peak)
Battery Voltage Sensor: 1K:10K (Scale 1100 in INAV, BATT_VOLT_MULT 11 in ArduPilot, Scale 110 in Betaflight)
Static power 110mA @5V

Power Board

Input voltage range: 7.4~ 36V (2~ 8S LiPo)
2x ESC power pads
Current Sense: 110A continuous, 132A peak. (Scale 250 in INAV, 40 A/V in ArduPilot,Scale 250in Betaflight)

BEC 5V output

Designed for FC, Receiver, OSD, Camera, 2812 LED Strip, GPS,Telemetry,etc.
Output 5.3 +/- 0.1V DC
Continuous current 3 Amps, 4.8A Peak

BEC VS output

Designed for Servos
Voltage adjustable, 5.3V Default, 7.2V option with Jumper pad
Continuous current 3 Amps, 4.8A Peak

BEC 3.3V output

Linear Regulator
Continuous current: 150mA

Mechanical

Mounting: 20 x 20mm, M2 hole
Dimensions: 25x 30 x 20 mm
Weight: 17g with USB extension board

Included:

1x Kakute F405-Wing Mini Flight Controller
1x Power Board
1x Bottom Board
1x USB-EXT Board
1x GPS Module (Optional)
1x Electrolytic capacitor: 2000uF 35v
3x Sets 2.54 DuPont Pin
1x 15cm JST-SH 6Pin Cable (For USB-EXT Board)
