If you’ve built a multirotor beforeย you’ll appreciate that there is a lot of wiring involvedย and it can be hard to keep all of itย neat and tidy. This board has been designed to simplify the wiring andย help keep it organised. It takes care of both power distribution and ESC signal wiring all in one neat package.
The board is designed for hexacopters so itย features six ESC signal inputs labeled M1 to M6. The connections are outputted together respectively at the signal hub, ready for you to connect withย your flight controller*. Onย the power distribution side of things, theย board has six coaxial power ports to power your ESCโs and a couple of XT30 connectors to power auxiliary devices like UBECs and FPV gear.
The board comes completes with a full wiring harness. It comes with six coaxial power cables and six signal wires, ready for you to solder to your ESC’s and then plug straight into the board. The cables are long; 66cm and 42cm respectively, so they haveย enoughย length if you prefer to mount your ESCโs under the motors away from the main frame. The packageย also comes with high currentย 10AWG power leads soldered to a 7mm gold plated Amass AS150 anti-spark battery connector. Finally, a foam adhesive pad is included which should be stuck to the back of the boardย to insulate itย from your frame.
*Important:ย The signal hub does not have a positive connection, only signal and ground connections.
