Speedy Bee TX800 5.8GHz FPV Video Transmitter

£31.90 Inc. VAT

One of our best selling VTXs. Can be powered from a single cell LiPo. Fits 20×20 flight stacks.

In stock

0 People watching this product now!

Description

Legal Notice: Please check with your local authorities regarding the operation of this equipment before you purchase. Regulations on power output, usable frequencies and licenses’ to operate vary from region to region.

The Speedy Bee TX800 is compact, high-efficiency video transmitter, offering a variable power output from 25mW up to 800mW and including a Pit Mode. It has IRC Tramp support for easy setting changes remotely via FC control, or you can use a simple push button on the VTX if you prefer. The transmitter only measures 28x28mm in size and is perfect in a stack with 20x20mm M2 mounting holes. The TX800 has a MMCX antenna connection, but it also includes a SMA pigtail adapter and a dipole whip antenna.

Speedy Bee also have great range for antennas to match, see here.

Specification

Frequency Channel: 5.8GHz 48CH
Output Power: PIT/25mW/200mW/400mW/800mW
Working Current: 5V@250~750mA
Voltage out: 5V@max 250mA
Voltage in: 3.7-5.5V
Video input impedance: 75 Ohm
Antenna Connector: MMCX
Weight: 5.6g (without antenna)
PCB Size: 28mmx28mm@20×20 M2

Included:

1x Speedy Bee TX800 5.8GHz Video Transmitter
1x MMCX Antenna
1x MMCX to SMA Cable
1x 1.0mm 4pin Cable
