7″ High Resolution FPV Monitor 32CH Diversity Rx & HDMI Input

£249.00 Inc. VAT

Looking forย professional grade FPV monitor? Look no further than this one.

Out of stock

This product is currently sold out.

No worries! Enter your email, and we'll let you know as soon as it's back in stock.

0 People watching this product now!
SKU: FPV-MONITOR-7IPSD Categories: , , , Tags: , , , ,
Description

Looking forย professional grade FPV monitor? Look no further than this one.

There are many FPV monitors on the market, but most are designed for the hobbyist and don’t cut it for professional applications. This monitor on the other handย looks fit for professional use and meets those demands to.ย With its high-resolution IPS panel display, built-in 32CHย dual receiver, PIP function andย HDMI input itโ€™s the perfect field monitor for professional aerial photographers.

What is an IPS Panel?

IPS is a technology of LCD screen. While lots of cheaper FPV screen use a TFT LCD display, this monitor boasts anย IPS screen, like that used by your iphone or other high-end smartphones. IPS screens offer a superior viewing angle, excellentย colour reproduction and great brightness, which is essentialย for outdoors use. Furthermore, it comes supplied with a removable sun shield for even greater clarity outdoors.

Dual 5.8Ghz Video Receivers

The monitor features an in built 5.8GHz diversity receiver (Rx) making it FPV ready. A diversity Rx is essentially two receivers in one. This allows you two mix and match antennas for a solid video link or display two serpate video feeds side by side known as a PIP (picture-in-picture). The PIP function is really useful for professional applications as it allows the pilotย to video theirย camera feed and FPV (pilot view)ย at the same time.ย The monitor’s diversity receiver operates over 5 bands and features auto scan,ย making it compatible with most FPV gear, including ImmersionRC, Fat Shark, Boscam amongst others. If you want to use the monitor to receive none FPV frequencies, there is an AV input and a HDMI input, so you could simply use the monitorย as an external display for other devices such as the DJI Lightbridge system.

Other Features:

The monitor comes with a built-in rechargeableย battery for a 3-4 hour working time. This can be extended further via the optional battery backplate, which can be fitted with a Canon DSLR camera battery (LP-E6).

Features:

  • Dual 5.8Ghz ultra sensitive video receivers
  • PIP function to display two video feeds
  • 7″ LCD Display w/ IPS panel 178ยฐ wide viewing angles
  • Fine resolution 1280ร—800
  • Very bright 400cd/ใŽก, good for using under sunlight
  • High contrast: 800:1
  • Faster response time
  • Slim & portable design
  • Built-in Rechargeable Battery
  • External power mount
  • No “blue screen” problem when the signal gets weak
Extend the running time of this screen with the optional external battery mount:

Battery Adapter for FPV Monitor7

What to add your company logo to the monitor splash screen? Please contact us for more information.

Monitor Logo Splash Screen

339DW DM Spec

Specification
  • Antenna Connector: SMA Female
  • Panel: 7″ IPS
  • Physical Resolution: 1280ร—800
  • Aspect Ratio: 16 : 9
  • Brightness: 400cd/ใŽก
  • Contrast: 800 : 1
  • Viewing Angle: 178ยฐ/178ยฐ(H/V)
  • Input: AV X 1, HDMI X1
  • Sound: Built-in Speaker X 1, Ear Phone Slot X 1
  • Current: 960mA
  • Input Voltage: 12V
  • Operating Temperature: -20โ„ƒ๏ฝž60โ„ƒ
  • Storage Temperature: -30โ„ƒ๏ฝž70โ„ƒ
  • Dimension(LWD): 185 ร— 126 ร— 30mm
  • Weight: 385g

Included:

  • 7″ FPV Monitor w/ Dual 5.8Ghz Video Receivers
  • 3.7V 2600mah Li-Po Battery X 1
  • AV Cable X 1
  • Audio Cable X 1
  • Battery Charger UK Plugย X 1
  • Sunshadeย X 1
