Walksnail Avatar HD Micro Kit V2 with Gyroflow (32GB)

£149.99 Inc. VAT

Walksnail Avatar HD Micro Kit V2 ‘air-unit’ with Gyroflow and masses of storage space for recording your flights.

Only 1 left in stock

0 People watching this product now!
SKU: HD-FPV-AVATHDV232-KIT Categories: , , , Tags: , , , , ,
Description

This version is the 32GB kitย and supports gyroflow.ย Enjoy the unparalleled performance and take your FPV adventures to new heights with this cutting-edge technology!

The Micro Camera V2 hasย a 4:3 sensor withย F/2.0 large aperture. Offeringย 1080P atย 120fpsย you can enjoy stunning image quality and a wide-angle FOV of 160ยฐ.ย The camera also supports Gyroflow technology, ensuring stable and smooth footage. The VTX has a redesigned PCB board with enhanced TVS protection and improved heatsink which makes it more robust. In addition to the JST connector, the VTX module now includes solder pads, allowing you to direct solder the VTX to your flight controller. In addition to the original 25mm x 25mm mounting holes, the kit now includes 20mm x 20mm holes for greater compatibility with a wider range of FPV drone models.

The video transmitter can be powered by a voltage of 6-25V (2-6S). When feeding directly from 6S batteries, a capacitor of at least 470uF/50V must be used at the input.

Compatible with HD Goggles such as theย Walksnail Avatarย andย Fat Shark HD Dominator

Avatar HD Pro Gyro

The camera ( 32G VTX KIT)ย supportsย Gyroflow, allowing you to capture smooth and stable video.

Micro Kit V2 AMicro Kit V2 B

Specification

AVATAR HD V2 CAMERA

  • Resolution: 1080P/60fps; 720P/100fps; 720P/60fps;1080P/120fps compatibility; 1080P/100fps compatibility;
  • Image Sensor: 1/3.2-Inch 4Mp 4:3sensor
  • Min.Illumination: 0.001Lux
  • Dimensions: 19*19*22mm
  • Coaxial Cable: 140mm
  • Shutter Rolling shutter
  • Ratio: 4:3 native /16:9
  • Gyroflow: supported
  • Aperture: F2.0
  • Lens: 2.1mm
  • Weight: 7.2g
  • FOV: 160ยฐ

AVATARย V2ย VTX

  • Transmitter Power (EIRP: FCC:<30dBm;CE:<14dBm;SRRC:<20dBm; MIC:<25dBm
  • Supported FC System: Betaflight; Inav; Fettec; ArduPilot;Kiss
  • 1/O Interface: JST1.0*4(Power in)JST0.8*6(USB)
  • Communication Frequency: 5.725-5.850GHz
  • Mounting Holes: 25.5*25.5mm; 20*20mm
  • Operating Temperature: -20-40โ„ƒ
  • Dimensions: 33.5*33.5*10.5mm
  • Latency: Average delay 22ms
  • Wide Power Input: 6V-25.2V
  • Model: Avatar V2 module
  • Recording: 1080p/720p
  • OSD: Canvas mode
  • Antenna: 1(IPEX)
  • Storage: 32GB
  • Weight: 17.6g
  • Channels: 8

AVATAR V2 ANTENNA

  • Frequency range: 5600MHz-6000MHz
  • Size: R15 X 45mm(without cable)
  • Input Impedance: 50ฮฉ
  • Polarization: LHCP
  • Interface: IPEX-1
  • Gain: 1.9dBi
  • VSWR: โ‰ค1.5
  • Weight: 2g

Included:

  • 1x Walksnail Avatar HD VTX V2 – 32GB w/ Gyro
  • 1x Walksnail Avatar HD Camera V2
  • 1x Walksnail Avatar Antenna V2
  • 1x USB transfer extension cable
  • 4x M2*5*0.5mm gasket
  • 1x 4 Pin silicone cable
  • 4x M2*14mm screws
  • 8x M2*4mm screws
  • 4x M2*5mm screws
  • 4x M2*6mm screws
