Name: Matek Servo PDB with 12A BEC 9-55V to 5/6/8V - Flying Tech
Brand: Matek Systems
SKU: PDB-MTSERVOPDB12A
Price: 19.90 GBP
Availability: OutOfStock

Matek Servo PDB with 12A BEC 9-55V to 5/6/8V

£19.90 Inc. VAT

This fixed-wing PDB features a dedicated BEC to power servos. It has 10 PWM outputs.

Out of stock

Notify me when item is back in stock.

0 People watching this product now!

Description

The Matek Servo PDB provides clean voltage regulation for servos and other accessories that require 5/6/8V. The board is useful for applications where the flight controller is without dedicated BEC to power servos or big-scale RC airplanes that have high power demands. The Servo PDB allows servos/escs to be powered external to a flight controller or receiver. It provides 10-PWM outputs and features an onboard BEC with adjustable 5V,6V,8V output. The Servo PDB is rated at 12A continuous and 20A burst.

Applications:

Flight controllers without dedicated BEC for servos
Reduces circuit loss and voltage drop on servo power wires for big scale RC Airplane

Specification

9V to 55V Operating Input Range
Vx for servos, 5V, 6V, 8V Adj. Default is 5V.
Synchronous switching step-down (buck) regulator with typical efficiencies of 88% to 96%
Supports continuous output current of up to 12A, peak current of 20A.
Standby current: 5~10mA
No protection for reversed input polarity
Thermal Shutdown
Output Short-circuit tolerant (2 seconds)
Overcurrent protection & self-recovery
Dropout voltage: 2V (Input>=10V is required for stable 8V output)
Pins distance: 2.54mm
Size & Weight: 50 x 27 x 8mm, 18g
Packing: 1x SVPDB-12S, Dupont 2.54mm pins shipped unsoldered
