Hobbywing XRotor 40A 2-6S OPTO Multirotor ESC

£17.99 Inc. VAT

This 40A ESC is a multirotor specific speed controller. It comes prewired with 3.5mm bullet connections.

Version

Clear

Add to compare

0 People watching this product now!

SKU: N/A Categories: Single ESCs, Electronics, Speed Controllers (ESCs) Tags: 40A, ESC, OPTO, Speed Controller, XRotor

Description

The Hobbywing X-Rotor series ESC are good quality multirotor speed controllers that have been widely proven to be reliable and deliver great performance. They have been specifically designed for multirotors and come preconfigured so that they are ready to use out of the box after a simple throttle calibration. They are compatible with all of the leading flight controllers, including Naza, APM, Pixhawk etc. and brushless motors including those with high pole counts and low Kv ratings. Finally, the firmware on these ESCs is tuned to deliver a very smooth linear throttle curve that is ideal for multirotor applications.

HobbyWing XRotor Features:

Special core program for multi-rotor controllers greatly improves throttle response
Specially optimized software for excellent compatibility with disc-type motors
Settings are preset, making usage simple, highly intelligent and adaptive
The twisted-pair design of the throttle signal cable effectively reduces the crosstalk produced in signal transmission and makes flight more stable
Compatible with various flight-control systems and supports a signal frequency of up to 621Hz (Note: all throttle signals over 500Hz are non-standard signals)
MOSFET with extra-low resistance brings high performance and great current endurance

Specification

Output: Continuous 40A, Burst 60A up to 10 seconds
Input Voltage: 2-6cells lithium battery
BEC: NO BEC
Refresh rate of the throttle signal: at least 400Mhz
Timing: High or Intermediate
Red Black cable length: 120mm
Signal cable length: 260mm
Bullet Connector: 3.5mm
Size: 68 x 25 x 8.7mm
Weight: 26g

Included:

1 X Hobbywing XRotor 40A OPTO ESC
1 X English Manual

Downloads

Manual (pdf, 1411KB)

Download

Q&A

Questions and answers of the customers

There are no questions yet. Be the first to ask a question about this product.

Advice

Here at Flying Tech we have a wide choice of electronic speed controllers (ESCs).

There are two main types of ESCs: 4-in-1 ESCs and single ESCs. A 4-in-1 ESC integrates four individual ESCs onto a single circuit board, each controlling a separate motor. A single ESC controls only one motor.

This 4-in-1 ESC is a more popular choice for racing quads, while single motor aircraft such as fixed wings would use a single ESC. Single ESCs are still used by some drone racers though, as after a crash or a burnt up ESC, they only have to replace one, not an entire 4-in-1 or stack which is a lot more costly. Single ESCs are also available which much greater current ratings (80amp +) so they are also used by power hungry multi-rotors, for example X-Class racing quads, professional camera flying “Cinelifters”.

When using individual ESCs, they typically need to be connected to a single power distribution board (PDB) or an “AIO flight controller” (a type of flight controller with integrated PDB) for power supply.
