Tarot 4006 620KV 4S Multirotor Brushless Disc Motor – TL68P02

Name: Tarot 4006 620KV 4S Multirotor Brushless Disc Motor - TL68P02 - Flying Tech
Brand: Tarot
SKU: M-620KV-TAROT
Price: 26.50 GBP
Availability: InStock

£26.50 Inc. VAT

Suits 3-4KG quad or hexacopter builds, such as the Tarot 680 Pro. Rated for 3-4S LiPo. Suggested prop size: 11-13inch.

In stock

Compare

0 People watching this product now!

SKU: M-620KV-TAROT Categories: Multirotor Motors (22XX +), Brushless Motors, Motors Tags: 620Kv, 680 Pro, Brushless Motor, Disc Motor, Motor, Outrunner, Pancake Motor

Description

Tarot make excellent multirotor frames, but they also manufacture well engineered motors to match. The 4006 620KV is a high-powered, super efficient 3-4S (11.1-14.8V) motor, specially designed for heavy lifting multirotors (3 to 4 kg). It lends itself to the FY650~FY690 Tarot frames but equally to any quad or hexacopter.

The motor utilises quality components such as a neodymium iron boron rotor, a high-precision CNC machined shell and large high-speed precision bearings. The motor features a high pole count for smooth and responsive power, and a turbofan cover, which provides excellent heat dissipation. Every motor is tested for concentricity and balanced for smooth running. The end result is a super efficient, vibration free, high performance motor.

The 4006 can be matched with 11″ to 13″ propellers. We sell compatible quick release prop adapters for the 4006, please see ‘Related Products’ below.

Recommended Propeller – Tarot 1355

Specification

Model: 4006 (TL68P02)
KV: 620KV
Power Supply: 3-4s LiPo
Suitable for: 3-4KG multirotor
Propeller mounting: Two Holes, M3 holes with 12mm spacing
Motor outer diameter: 46mm
Motor height: 22.0mm
Stator diameter: 40.6m
Motor pole number: 22P
Shaft diameter: 4mm
Weight: 82g
Max thrust (1355 Prop): 1.58kg
Motor resistance: 126 M.
No load current 14.8V: 0.8A
Motor mounting specifications: 27mm equilateral triangle

Includes:

4006/620KV brushless motor x 1
Socket head cap screw (M3 x 6mm) x 4
Round head screw (M3 x 8mm) x 3
Propeller washer x 1

Downloads

Datasheet (jpg, 74KB)

Download
