Matek Optical Flow & Lidar Sensor 3901-L0X

£24.90 Inc. VAT

Useful for indoor applications when GPS doesn’t work. This sensor can provide a position lock and altitude hold capability.

In stock

0 People watching this product now!
Description

This sensor works the same way as an optical mouse, helping your iNAV quad maintain positionย without GPS! It has a working range of up to 2m, and uses a VL53L0X Lidar rangefinder along with a PMW3901 optic flow module. The sensor is connected to your flight controller via a UART and is currently only supported by INAVย –ย other firmware projects like betaflight will support this sensor in the future.

Tips:

  • Be sure Optical Flow lens is more than 2cm way from anything for optic flow to initialise correctly while FC starting up.
  • Maximum range of VL53L0X is 2m, Altitude hold 0~2m @ throttle 0~100% if VL53L0X is enabled.
  • Any unused UART of FC supports it
  • Sonar connection (Trig & Echo) has not been implemented yet

image 21image 25

image 26

Specification
  • Optical Flow: PMW3901
  • Lidar: VL53L0X
  • Interface UART
  • Protocol: INAV MSP
  • Working Range: 8cm~200cm
  • Field of view: 42 degree(PMW3901), 27 degree(VL53L0X)
  • Minimum Illumination >60Lux
  • Input voltage: 4.5~5.5V
  • Power Consumption: 40mA
  • Size: 36x12mm, 2g

Included:

  • 1 xย Matek Optical Flow & Lidar Sensor – 3901-L0X
Downloads
Manual (pdf, 113KB)
