This has to be the ultimate power distribution board (PDB) for any mini quad. It’s much more than just a simple PDB, it’s better described as a power hub. It has both 5v and 12v regulated BECs, a LED light controller and even lost plane finder & low voltage alarm functions.
The board has been designed to suit FPV mini quads and help simplify their builds. The 5V 3amp BEC is ideal for powering a flight controller (FC) or RC receiver (Rx). Its wiring is a doodle, simply use the provided servo cable to connect your FC/Rx directly to the 5v aux pins to get power. On the other hand, the 12V BEC output has been designed with FPV systems in mind and could be used to power a FPV camera or FPV transmitter. To step down the flight battery voltage to 12v, it uses a linear regulator, which is better than a switching type regulator for FPV applications. A linear regulator reduces output voltage ripple and does not emit radio frequency interference, like switching regulators sometimes do.
Aside from the power hub functions, the board also features four 5v LED connections and a LED light controller that can be operated remotely via the aux channel or via the push button on the board itself. The LEDs can be switch on/off and set to three different working modes: constant, slow flash or fast flash.
In addition to the LED controller, the board also features a buzzer, which can be activated to help you find your model in long grass, or act as a low voltage alarm. Once the voltage gets below the threshold you set, the buzzer & LED light will activate to alert you that it’s time to change batteries.
Recommended LEDs: Matek RGB 5050 7 Colour DIP Switch LED Light Board
Features:
- 5 function power hub
- High quality 2oz copper, 4 layer PCB
- Regulated 5V & 12V BEC outputs, supports 2-6S LiPo (7-26V DC)
- 4x 5V LED outputs
- LED driver – 4 modes: Off / constant / slow flash / fast flash
- Lost plane finder / low voltage alarm
- 30.5×30.5mm holes (stackable with Naze32, CC3D etc.)
