Matek H743 Slim V3 30×30 Flight Controller

Name: Matek H743 Slim V3 30x30 Flight Controller - Flying Tech
Brand: Matek Systems
SKU: FC-H743-SLIMV3
Price: 89.70 GBP
Availability: InStock

£89.70 Inc. VAT

Loaded with an array of features and tons of room for peripherals, this board lets you choose how you want to fly.

Only 2 left in stock

Compare

0 People watching this product now!

SKU: FC-H743-SLIMV3 Categories: Racing Drone Flight Controllers, Electronics, Flight Controllers / Autopilots Tags: Ardupilot, FC, Flight Controller, H7, iNav

Description

FLIGHT CONTROLLER H743-SLIM V3

STM32H743VIT6, ICM42605 & ICM42688P, DPS310, OSD, 7x UARTs, 2x I2C, 1x CAN, 13x PWM outputs, BEC5V

Loaded with an array of features and tons of room for peripherals, this board lets you choose how you want to fly. It’s compatible with INAV, Betaflight, and ArduPilot. New features in the H743-SLIM include switchable dual camera inputs and a max voltage of 36V(8S). Alongside its ultra fast H7 480MHz processor, the specification includes dual gyros (IMU ICM42688P, ICM42605), an Infineon DPS310 barometer, built in AT7456E OSD (On Screen Display), 13 PWM outputs, 7x UARTs, 2x I2C, 1x CAN, a 5V UBEC, switchable camera inputs and finally a MicroSD card slot for blackbox logging.

Current version is V3.

Versions:

V1, IMU MPU6000, ICM20602
V1.5, IMU MPU6000, ICM42605
V3, IMU ICM42688P, ICM42605

Specification

MCU: STM32H743VIH6, 480MHz , 1MB RAM, 2MB Flash
IMU: ICM42688P (SPI1) & ICM42605 (SPI4)
Baro: Infineon DPS310 (I2C2)
OSD: AT7456E (SPI2)
Blackbox: MicroSD card socket (SDIO)
7x Uarts (1,2,3,4,6,7,8) with built-in inversion.
13x PWM outputs(including “LED” pad)
2x I2C
1x CAN
6x ADC (VBAT, Current, RSSI, Analog AirSpeed, Vbat2, Cur2)
3x LEDs for FC STATUS (Blue, Red) and 3.3V indicator(Red)
1x SPI3 breakout
USB Type-C(USB2.0)
1x JST-SH1.0_8pin connector (Vbat/G/Curr/Rx8/S1/S2/S3/S4)
1x JST-GH1.25_4pin connector (5V/CAN-H/CAN-L/G)
Dual Camera Inputs switch
5V/Vbat filtered power ON/OFF switch
DJI FPV OSD is supported by any spare UART

Power

Vbat Input: 6~36V (2~8S LiPo)
BEC: 5V 2A cont. (Max.3A)
LDO 3.3V: Max.200mA
No Current Sensor built-in
ADC Vbat2 pad supports Max. 69V (voltage divider: 1K:20K)
Static power: 200mA@5V with Betaflight, 150mA@5V with ArduPilot
FC Firmware
ArduPilot(ChiBiOS): MATEKH743
BetaFlight: MATEKH743
INAV: MATEKH743 (To be supported soon)
Physical
Mounting: 30.5 x 30.5mm, Φ4mm with Grommets Φ3mm
Dimensions: 36 x 36 x 5 mm
Weight: 7g

Included:

1 x H743-SLIM V3
6 x Silicon grommets M4 to M3
1 x JST-SH1.0_8pin cable, 5cm
2 x JST-SH1.0_8pin connectors
1 x JST-GH-4P to JST-GH-4P cable for CAN port, 20cm
